Meanwell SE-200-5 Power Supply

Tính Năng:

Có thể chọn dải đầu vào AC bằng công tắc
Bảo vệ: Ngắn mạch / Quá tải / Quá áp / Quá nhiệt
Làm mát bằng đối lưu không khí tự do
Chịu được đầu vào đột biến 300VAC trong 5 giây
Tích hợp mạch giới hạn dòng điện không đổi
Kiểm tra ghi trong toàn bộ tải 100%
Chỉ báo LED để bật nguồn
Tần số chuyển mạch cố định ở 90KHz
Chi phí thấp, độ tin cậy cao

Thông số chi tiết về sản phẩm

Model		SE-200-3.3	SE-200-5	SE-200-7.5	SE-200-12	SE-200-15	SE-200-24	SE-200-27	SE-200-36	SE-200-48
OUPUT	DC VOLTAGE	3.3V	5V	7.5V	12V	15V	24V	27V	36V	48V
	RATED CURRENT	40A	40A	27A	17A	14A	8.8A	7.8A	5.9A	4.4A
	CURRENT RANGE	0 ~ 40A	0 ~ 40A	0 ~ 27A	0 ~ 17A	0 ~ 14A	0 ~ 8.8A	0 ~ 7.8A	0 ~ 5.9A	0 ~ 4.4A
	RATED POWER	132W	200W	202.5W	204W	210W	211.2W	210.6W	212.4W	211.2W
	RIPPLE & NOISE (max.) Note.2	150mVp-p	150mVp-p	150mVp-p	150mVp-p	150mVp-p	150mVp-p	200mVp-p	240mVp-p	240mVp-p
	VOLTAGE ADJ. RANGE	2.97 ~ 3.7V	4.5 ~ 5.6V	6 ~ 9V	10 ~ 13.5V	13.5 ~ 18V	20 ~ 26.4V	26 ~ 32V	32 ~ 40V	41 ~ 56V
	VOLTAGE TOLERANCE Note.3	±2.0%	±2.0%	±2.0%	±1.0%	±1.0%	±1.0%	±1.0%	±1.0%	±1.0%
	LINE REGULATION	±0.5%	±0.5%	±0.5%	±0.5%	±0.5%	±0.5%	±0.5%	±0.5%	±0.5%
	LOAD REGULATION	±1.5%	±1.0%	±1.0%	±0.5%	±0.5%	±0.5%	±0.5%	±0.5%	±0.5%
	SETUP, RISE TIME	1000ms, 50ms/230VAC 1000ms,50ms/115VAC at full load
	HOLD UP TIME (Typ.)	20ms/230VAC 16ms/115VAC at full load
INPUT	VOLTAGE RANGE Note.4	90 ~ 132VAC / 180 ~ 264VAC selected by switch 254 ~ 370VDC
	FREQUENCY RANGE	47 ~ 63Hz
	EFFICIENCY (Typ.)	75%	79%	82%	85%	85%	87%	88%	89%	89%
	AC CURRENT (Typ.)	4.5A/115VAC 2.5A/230VAC
	INRUSH CURRENT (Typ.)	40A/115VAC 55A/230VAC
	LEAKAGE CURRENT	<3.5mA / 240VAC
PROTECTION	OVER LOAD	105 ~ 150% rated output power
	OVER LOAD	Protection type : Constant current limiting, recovers automatically after fault condition is removed
	OVER VOLTAGE	3.8 ~ 4.9V	5.75 ~ 7.0V	9.4 ~ 10.9V	13.8 ~ 16.2V	18 ~ 21V	27.6 ~ 32.4V	33.7 ~ 39.2V	41.4 ~ 46.8V	57.6 ~ 67.2V
	OVER VOLTAGE	Protection type : Shut down O/P voltage, re-power on to recover
	OVER TEMPERATURE	95⁰C±5⁰C(3.3V);100⁰C ±5⁰C(5V);90⁰C±5⁰C(7.5V);85⁰C±5⁰C(12~24V);80⁰C±5⁰C(27~36V);75⁰C±5⁰C(48V) (TSW1) Detect on case
	OVER TEMPERATURE	Protection type : Shut down O/P voltage, recovers automatically after fault condition is removed
ENVIRONMENT	WORKING TEMP.	20 ~ +50⁰C (Refer to output load derating curve)
	WORKING HUMIDITY	20 ~ 90% RH non- condensing
	STORAGE TEMP., HUMIDITY	20 ~ +85⁰C, 10 ~ 95% RH
	TEMP. COEFFICIENT	±0.03%/⁰C (0 ~ 50⁰C)
	VIBRATION	10 ~ 500Hz, 3G 10min./1cycle, 60min. each along X, Y, Z axes
